About This Product
Our dehumidifiers are equipped with a high-performance Prolute rotary desiccant wheel, delivering exceptional moisture removal efficiency and long-term durability. The advanced U-type fan system ensures strong and stable airflow, enabling rapid and uniform dehumidification across the entire space.
To further enhance performance, the unit integrates a PTC heating element, providing reliable, energy-efficient regeneration with extended service life. Designed specifically for low-temperature and high-humidity environments, this system maintains precise humidity control and optimal air quality even under demanding conditions.
The unit also features an SCR-controlled energy-saving system, allowing intelligent power regulation and reduced operating costs. With a dedicated reactivation air inlet, installation is flexible and convenient, ensuring smooth and efficient operation.
|
Model |
YS-200C |
YS-400C |
YS-600C |
YS-800C |
YS-1000C |
YS-1200C |
|
Power Supply |
220V/50Hz |
AC220V 50Hz |
220V/50Hz |
380V/50Hz |
380V/50Hz |
380V/50Hz |
|
Dehumidification Capacity |
20L/D |
2KG/h |
72L/D |
108L/D |
180L/D |
192L/D |
|
Test Conditions |
T=20℃，RH=60% |
T=20℃，RH=60% |
T=20℃，RH=60% |
T=20℃，RH=60% |
T=20℃，RH=60% |
T=20℃，RH=60% |
|
Rated Power |
1.2KW |
2KW |
4KW |
7KW |
9KW |
11KW |
|
Rated Current |
5.4A |
9A |
16A |
17A |
20A |
24A |
|
Air Handling Capacity |
200 m3/h |
400 m3/h |
600 m3/h |
800 m3/h |
1000 m3/h |
1200 m3/h |
|
Regeneration Airflow Capacity |
80 m3/h |
150 m3/h |
250 m3/h |
320 m3/h |
400 m3/h |
450 m3/h |
|
Air Handling Static Pressure |
100Pa |
110Pa |
100Pa |
120Pa |
250Pa |
295Pa |
|
Regeneration Airflow Static Pressure |
60pa |
85pa |
90pa |
80Pa |
130pa |
160pa |
|
Air Inlet Diameter for Processing |
Φ100 mm*2 |
Φ120 mm*2 |
Φ150 mm*2 |
Φ200 mm*2 |
Φ200 mm*2 |
Φ200 mm*2 |
|
Air Inlet Diameter for Regeneration |
Φ75 mm*2 |
Φ100 mm*2 |
Φ100 mm*2 |
Φ120 mm*2 |
Φ150 mm*2 |
Φ150 mm*2 |
|
Dehumidification Rotor |
200*50 |
250*100 |
300*100 |
350*200 |
450*100 |
450*100 |
|
Filtration System |
Primary Filter |
Primary Filter |
Primary Filter |
Primary Filter |
Primary Filter |
Primary Filter |
|
Operating Temperature Range |
-10℃～50℃ |
-10℃～50℃ |
-10℃~50℃ |
-10~+50℃ |
-10℃~50℃ |
-10℃~50℃ |
|
Dimensions |
466*333*655 mm |
721*425*403 mm |
612*433*856 mm |
1090*600*697 mm |
820*600*1100 mm |
820*600*1100 mm |
|
Weight |
30 kg |
45kg |
75kg |
90 kg |
110kg |
130kg |
|
FOB |
$859 |
$809 |
$1,329 |
$2,139 |
$3,000 |
$3,239 |
|
Model |
YS-1500C |
YS-1800C |
YS-2500C |
YS-3000C |
YS-4000C |
YS-1200C |
|
Power Supply |
380V/50Hz |
380V/50Hz |
380V/50Hz |
380V/50Hz |
380V/50Hz |
380V/50Hz |
|
Dehumidification Capacity |
240L/D |
288L/D |
15kg/h |
20kg/h |
25kg/h |
192L/D |
|
Test Conditions |
T=20℃，RH=60% |
T=20℃，RH=60% |
T=20℃，RH=60% |
T=20℃，RH=60% |
T=20℃，RH=60% |
T=20℃，RH=60% |
|
Rated Power |
15KW |
17KW |
24KW |
30KW |
35KW |
11KW |
|
Rated Current |
28A |
32A |
40A |
50A |
60A |
24A |
|
Air Handling Capacity |
1580 m3/h |
1850 m3/h |
2500 m3/h |
3000 m3/h |
4000 m3/h |
1200 m3/h |
|
Regeneration Airflow Capacity |
550 m3/h |
650 m3/h |
900 m3/h |
1100 m3/h |
1500 m3/h |
450 m3/h |
|
Air Handling Static Pressure |
360Pa |
380Pa |
400Pa |
420Pa |
450Pa |
295Pa |
|
Regeneration Airflow Static Pressure |
230Pa |
260Pa |
280Pa |
300Pa |
350Pa |
160pa |
|
Air Inlet Diameter for Processing |
Φ250 mm*2 |
Φ250 mm*2 |
Φ250 mm*2 |
Φ400 mm*2 |
Φ400 mm*2 |
Φ200 mm*2 |
|
Air Inlet Diameter for Regeneration |
Φ150 mm*2 |
Φ150 mm*2 |
Φ150 mm*2 |
Φ250 mm*2 |
Φ250 mm*2 |
Φ150 mm*2 |
|
Dehumidification Rotor |
570*200 |
570*200 |
570*200 |
700*200 |
700*200 |
450*100 |
|
Filtration System |
Primary Filter |
Primary Filter |
Primary Filter |
Primary Filter |
Primary Filter |
Primary Filter |
|
Operating Temperature Range |
-10~50℃ |
-10~50℃ |
-10~50℃ |
-10~50℃ |
-10~50℃ |
-10~50℃ |
|
Dimensions |
920*683*1307 mm |
920*683*1307 mm |
920*683 *1307 mm |
1135*833*1360 mm |
1135*835*1360 mm |
820*600*1100 mm |
|
Weight |
210kg |
230kg |
280 kg |
330 kg |
380 kg |
130kg |
|
FOB |
$4,500 |
$4,700 |
$5,400 |
$8,100 |
$9,000 |
$3,239 |
Frequently Asked Questions
We collect a lot of FAQs from our real clients and please check out our FAQ page. Also, feel free to chat with us via LiveChat, phone call, email, or just simply drop us a line below:
30% to 50% for most indoor spaces. Industrial settings may require specific humidity levels. Our machine adjustable humidity range is 10%-90%.
Dehumidifiers are ideal for a wide range of industries, including pharmaceuticals, electronics, food processing, archives, data centers, museums, and industrial manufacturing environments.
A dehumidifier works by drawing in air, removing excess moisture using a cooling or desiccant system, and then releasing dry air back into the room. This process helps reduce humidity levels, preventing mold, mildew, and moisture damage.
We offer a full range of solutions, including refrigeration dehumidifiers, rotary wheel (desiccant) dehumidifiers, low-temperature models, high-temperature models, and customized climate control systems.
Yes, we support OEM & ODM services. We can customize capacity, voltage, appearance, and control systems based on your project requirements.
Our MOQ is flexible depending on the product type. Sample orders are available for testing before bulk purchase.
Standard models are typically delivered within 7–15 days. Customized orders may require additional time depending on specifications.
Our products can comply with international standards such as CE and other certifications required by your market.
Simply provide your application details (area, temperature, humidity level, etc.), and our team will recommend the most suitable solution.
